Product Summary
The 5016462400 is a 2.00mm (.079") Pitch iGrid Wire-to-Board Housing.
Parametrics
5016462400 absolute maximum ratings: (1)Circuits (maximum) 24; (2)Color - Resin Natural; (3)Gender Female; (4)Glow-Wire Compliant No; (5)Lock to Mating Part Yes; (6)Material - Resin Nylon; (7)Number of Rows 2; (8)Packaging Type Bag; (9)Panel Mount No; (10)Pitch - Mating Interface (in) 0.079 In; (11)Pitch - Mating Interface (mm) 2.00 mm; (12)Polarized to Mating Part Yes; (13)Stackable No; (14)Temperature Range - Operating -25 to +85℃.
Features
5016462400 features: (1)Product Family Crimp Housings; (2)Series 501646; (3)MolexKits Yes; (4)Overview igrid; (5)Product Name iGrid.
Diagrams
 |
