Product Summary
The DIR9001PW is a digital audio interface receiver that can receive a 28-kHz to 108-kHz sampling-frequency, 24-bit-data-word, biphase-encoded signal. The DIR9001PW complies with IEC60958-3, JEITA CPR-1205 (Revised version of EIAJ CP-1201), S, AES3, EBUtech3250, and it can be used in various S, applications that require a digital audio interface. The applications of the DIR9001PW include AV/DVD Receiver, AV Amplifier, Car or Mobile Audio System, Digital Television, Musical Instruments, Recording Systems, High-End Audio/Sound Card for PC, Replacement of DIR1703, Other Applications Requiring S/PDIF Receiver.
Parametrics
DIR9001PW absolute maximum ratings: (1)Supply voltage: –0.3 to 4 V; (2)Supply voltage differences: ±0.1 V; (3)Ground voltage differences: ±0.1 V; (4)Digital input voltage: Digital input: –0.3 to 6.5 V, Digital output: –0.3 to (VDD + 0.3) < 4 V; (5)Analog input voltage: XTI, XTO –0.3 to (VCC + 0.3) < 4 V, FILT –0.3 to (VCC + 0.3) < 4 V; (6)Input current (any pins except supplies): ±10 mA; (7)Ambient temperature under bias: –40 to 125 ℃; (8)Storage temperature: –55 to 150 ℃; (9)Junction temperature: 150 ℃; (10)Lead temperature (soldering): 260 ℃, 5 s; (11)Package temperature (reflow, peak): 260 ℃.
Features
DIR9001PW features: (1)One-Chip Digital Audio Interface Receiver (DIR) Including Low-Jitter Clock-Recovery System; (2)Compliant With Digital Audio Interface Standards: IEC60958 (former IEC958), JEITA CPR-1205 (former EIAJ CP-1201, CP-340), AES3, EBU tech3250; (3)Clock Recovery and Data Decode From Biphase Input Signal, Generally Called S/PDIF, EIAJ CP-1201, IEC60958, AES/EBU; (4)Biphase Input Signal Sampling Frequency (fS) Range: 28 kHz to 108 kHz; (5)Low-Jitter Recovered System Clock: 50 ps.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 DIR9001PW |
Texas Instruments |
Audio Transmitters, Receivers, Transceivers 96kHz Digital Audio Receiver |
Data Sheet |
|
|
||||||||||||
|
DIR9001PWG4 |
Texas Instruments |
Audio Transmitters, Receivers, Transceivers 96kHz Digital Audio Receiver |
Data Sheet |
|
|
||||||||||||
|
DIR9001PWR |
Texas Instruments |
Audio Transmitters, Receivers, Transceivers 96kHz Digital Audio Receiver |
Data Sheet |
|
|
||||||||||||
|
DIR9001PWRG4 |
Texas Instruments |
Audio Transmitters, Receivers, Transceivers 96kHz Digital Audio Receiver |
Data Sheet |
|
|
||||||||||||
