MBR20100CT

switch mode power rectifier, SCHOTTKY, TO-220, 150Amps, 20 Amps Total

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.30~0.50

PartNumber:: MBR20100CT

Brand:: ON Semiconductor - ON | Pack: TO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-08-04

From Other Seller

Part Number:MBR20100CT
US $0.30 - 0.50
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MBR20100CT is a switch mode power rectifier.

Parametrics

MBR20100CT absolute maximum ratings: (1)Average Rectified Forward Current (Rated VR) TC = 133℃, IF(AV): 10Amps; (2)Peak Repetitive Forward Current (Rated VR, Square Wave, 20 kHz), TC = 133℃, IFRM: 20Amps; (3)Nonrepetitive Peak Surge Current, IFSM: 150Amps; (4)Peak Repetitive Reverse Surge Current (2.0 ms, 1.0 kHz), IRRM: 0.5Amp; (5)Operating Junction Temperature, TJ: -65 to +150℃; (6)Storage Temperature, Tstg: -65 to +175℃; (7)Voltage Rate of Change (Rated VR), dv/dt: 10,000V/ms.

Features

MBR20100CT features: (1)20 Amps Total (10 Amps Per Diode Leg); (2)Guard–Ring for Stress Protection; (3)Low Forward Voltage; (4)150℃ Operating Junction Temperature; (5)Guaranteed Reverse Avalanche; (6)Epoxy Meets UL94, VO at 1/8,; (7)Low Power Loss/High Efficiency; (8)High Surge Capacity; (9)Low Stored Charge Majority Carrier Conduction.
