Product Summary

2SJ49 is a kind of silicon p-channel MOSFET which is also a kind of low-frequency power amplifier.

Parametrics

2SJ49 absolute maximum ratings:(1)Drain-source voltage: -140V; (2)Gate-Source voltage: ±14V; (3)Drain current: -7A; (4)Body-Drain diode reverse drain current: -7A; (5)Channel Dissipation: 100w; (6)Channel temperature: 150℃; (7)Storage temperature: -55 ~+150℃.

Features

2SJ49 features: (1)High power gain; (2)Excellent frequency response; (3)High speed switching; (4)Wide area of safe operation; (5)Enhancement-mode; (6)Good complementary characteristics; (7)Equipped with Gate protection diodes.

Diagrams

2SJ49 test circuit
