Product Summary

The G6B-1184P is a subminiature relay that switches up to 5A.

Parametrics

G6B-1184P ratings: (1)Load: Resistive load (cosφ = 1); Inductive load (cosφ = 0.4; L/R = 7 ms); (2)Rated load: 8 A at 250 VAC; 8 A at 30 VDC; 2 A at 250 VAC; 2 A at 30 VDC; (3)Contact material: Ag Alloy (Cd free); (4)Rated carry current: 8 A; (5)Max. switching voltage: 380 VAC, 125 VDC; (6)Max. switching current: 8 A; (7)Max. switching capacity: 2,000 VA, 150 W; (8)Min. permissible load: 10 mA at 5 VDC.

Features

G6B-1184P features: (1)Subminiature: 20 × 10 × 10 mm (L × W × H).; (2)Low power consumption: 200 mW.; (3)Unique moving loop armature reduces relay size, magnetic interference, and contact bounce time; (4)Fully sealed construction; (5)Single and Dual coil latching types also available.; (6)High Capacity versions available; (7)RoHS Compliant.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
G6B-1184P-US DC12
G6B-1184P-US DC12
Omron Electronics
General Purpose / Industrial Relays Power PCB Relay
Data Sheet
0-1: $4.01
1-25: $3.80
25-50: $3.50
50-100: $3.19
G6B-1184P-US DC24
G6B-1184P-US DC24
Omron Electronics
General Purpose / Industrial Relays Power PCB Relay
Data Sheet
0-1: $4.32
1-25: $3.92
25-50: $3.59
50-100: $3.32
G6B-1184P-USDC12
G6B-1184P-USDC12

RELAY GEN PURPOSE SPST 8A 12V
Data Sheet
0-100: $3.71
G6B-1184P-USDC24
G6B-1184P-USDC24

RELAY GEN PURPOSE SPST 8A 24V
Data Sheet
0-100: $3.89
